Dodo - UKB Phenotype Network Visualisation

Live Application: dodo.biobankly.com

Dodo is a powerful, interactive web application for visualising UK Biobank phenotype networks at scale. Born from research at Biobankly LTD, this tool is designed to help researchers and scientists explore real-world phenotype connections, discover patterns, and extract high-impact signals from the UK Biobank cohort.

This repository contains the full source code for the Dodo application.

---

✨ Key Features

• Interactive Tree Visualisations: Uses D3.js to render fast, interactive TidyTree and Radial TidyTree layouts for complex hierarchical data.
• Advanced Filtering: Interactively map, filter, and extract high-impact signals.
• Cluster Navigation: Seamlessly zoom into and explore specific phenotype groupings to uncover meaningful patterns.
• Data Export: Select and export nodes, edges, or entire views for offline analysis.
• Insight Generation: View automatically generated summaries to quickly understand group dynamics and outliers.

---

💻 Technology Stack

This project is built with a modern, full-stack JavaScript stack:

• Framework: Next.js (React)
• Language: TypeScript
• Styling: Tailwind CSS
• Data Visualisation: D3.js
• Backend & Database: Supabase (Postgres, Auth, Realtime)
• Deployment: Vercel (Frontend) & Supabase (Backend/DB)
• Runtime: Node.js

---

🚀 Getting Started

To get a local copy up and running, follow these steps.

Prerequisites

You will need the following tools installed on your system:

• Node.js (v18 or higher recommended)
• npm (comes with Node.js)
• A free Supabase account to host your own database.

Installation & Setup

1. Clone the repo:

   git clone [https://github.com/donphi/dodo.git](https://github.com/donphi/dodo.git)
   cd dodo

2. Install dependencies:

   npm install

3. Set up Supabase Environment:

   • Log in to your Supabase account and create a new project.
   • Go to your project's Settings > API.
   • Find your Project URL and Project API Keys (the public anon key).
   • Create a .env.local file in the root of the dodo directory by copying the example:

     cp .env.example .env.local

   • Edit the .env.local file and add your Supabase credentials:

     NEXT_PUBLIC_SUPABASE_URL="YOUR_SUPABASE_URL_HERE"
     NEXT_PUBLIC_SUPABASE_ANON_KEY="YOUR_SUPABASE_ANON_KEY_HERE"

   • Note: You will also need to run the database migrations/seed data to populate your database. (You should add instructions here on how to do that, e.g., npx supabase db push or by running a seed script).

Running Locally

1. Start the development server:

   npm run dev

2. Open http://localhost:3000 (or the port shown in your terminal) in your browser.

---

⚖️ License

Distributed under the MIT License. See LICENSE file for more information.

---

Acknowledgements

• UK Biobank
• Next.js
• D3.js
• Supabase
• Vercel
