System Designer MCP Server

A Model Context Protocol (MCP) server that provides AI agents with tools to create, validate, and export UML system models and System Runtime bundles. Built with a tool-based approach that empowers LLMs to generate complete, executable System Runtime applications.

📚 Documentation

• API Reference - Detailed API documentation for all MCP tools
• System Runtime Integration Guide - Complete guide to System Runtime bundle creation
• Cloudflare Deployment Guide - Deploy to Cloudflare Workers as remote MCP server
• CLI Guide - Command-line interface usage and examples
• Integration Guide - Platform integration instructions
• Examples - Sample models and use cases
• Contributing Guide - How to contribute to the project
• Code of Conduct - Community guidelines and behavior expectations
• Security Policy - Security vulnerability reporting and policies

Features

Core MSON Tools

• create_mson_model: Create and validate MSON models from structured data
• validate_mson_model: Validate MSON model consistency and completeness
• generate_uml_diagram: Generate UML diagrams in PlantUML and Mermaid formats
• export_to_system_designer: Export models to System Designer application format

System Runtime Tools

• create_system_runtime_bundle: Convert MSON models to complete System Runtime bundles
• validate_system_runtime_bundle: Validate System Runtime bundles for correctness and compatibility

Key Capabilities

• ✅ Tool-Based Architecture: LLMs handle understanding, server handles validation/formatting
• ✅ Type Safety: Comprehensive Zod schema validation for all inputs and outputs
• ✅ System Runtime Integration: Full support for System Runtime bundle generation and validation
• ✅ Bidirectional Relationships: Automatic bidirectional relationship creation
• ✅ Multiple Inheritance: Support for classes implementing multiple interfaces
• ✅ Multiple UML Formats: Support for both PlantUML and Mermaid diagram generation
• ✅ System Designer Integration: Direct export to System Designer macOS application
• ✅ Comprehensive Testing: 46 tests with 302 expect() calls covering all functionality
• ✅ Critical Bug Fixes: Resolved SDMCP-001 through SDMCP-005 (property preservation, ID management, validation consistency)
• ✅ Streamable HTTP Transport: Modern MCP protocol (2025-03-26 specification)
• ✅ Stateless Operation: Each request creates new server instance
• ✅ Single Endpoint: Single /mcp endpoint handles all operations
• ✅ Workers Optimized: Stateless design perfect for Cloudflare Workers

Installation

Prerequisites

• Bun JavaScript runtime
• Node.js compatibility through Bun

Setup

# Clone the repository
git clone https://github.com/chevyphillip/system-designer-mcp.git
cd system-designer-mcp

# Install dependencies
bun install

# Build the project
bun run build

# Run tests
bun test

Quick Start

# Clone the repository
git clone https://github.com/chevyphillip/system-designer-mcp.git
cd system-designer-mcp

# Install dependencies
bun install

# Build the project
bun run build

# Run tests
bun test

Deployment Options

The System Designer MCP Server can run in two modes:

Local Mode (stdio transport)

Start the local server:

bun run dev

Remote Mode (Cloudflare Workers)

Deploy as a remote MCP server accessible over HTTP with SSE transport:

# Test locally with Wrangler
bun run dev:worker

# Deploy to Cloudflare Workers
bunx wrangler login
bun run deploy

Your MCP server will be available at:

https://system-designer-mcp.<your-subdomain>.workers.dev

Note: Replace <your-subdomain> with your actual Cloudflare Workers subdomain.

Key Features:

• ✅ SSE (Server-Sent Events) transport for remote access
• ✅ No authentication required (configurable)
• ✅ All 6 MCP tools available
• ✅ Returns JSON data directly (no file system)
• ✅ Automatic session management
• ✅ CORS support for web clients

See CLOUDFLARE_DEPLOYMENT.md for detailed deployment instructions.

Usage Examples

Example tool usage:

// Create a MSON model
const model = await mcpClient.callTool('create_mson_model', {
  name: 'Student Management System',
  type: 'class',
  description: 'A system for managing students and courses',
  entities: [
    {
      id: 'student',
      name: 'Student',
      type: 'class',
      attributes: [
        { name: 'id', type: 'string', visibility: 'private' },
        { name: 'name', type: 'string', visibility: 'public' },
      ],
      methods: [{ name: 'enroll', returnType: 'void', visibility: 'public' }],
    },
  ],
  relationships: [],
});

// Generate UML diagram
const diagram = await mcpClient.callTool('generate_uml_diagram', {
  model: model.content[1].json,
  format: 'plantuml',
});

// Export to System Designer
const exported = await mcpClient.callTool('export_to_system_designer', {
  model: model.content[1].json,
  filePath: './student_system.json',
});

// Create System Runtime bundle
const bundle = await mcpClient.callTool('create_system_runtime_bundle', {
  model: model.content[1].json,
  version: '1.0.0',
});

// Validate System Runtime bundle
const validation = await mcpClient.callTool('validate_system_runtime_bundle', {
  bundle: bundle.content[2].text, // JSON bundle from previous step
});

CLI Usage

The server includes a CLI tool for testing and model management:

# Test System Designer integration
bun run src/cli.ts test-integration

# Export a test model
bun run src/cli.ts export-model MyModel "Test model description"

# Show configuration
bun run src/cli.ts config

See the CLI Guide for detailed usage instructions.

Example MSON Model Structure

{
  "id": "student_system",
  "name": "Student Management System",
  "type": "class",
  "description": "A system for managing students and courses",
  "entities": [
    {
      "id": "student",
      "name": "Student",
      "type": "class",
      "attributes": [
        {
          "name": "id",
          "type": "string",
          "visibility": "private"
        },
        {
          "name": "name",
          "type": "string",
          "visibility": "public"
        }
      ],
      "methods": [
        {
          "name": "enroll",
          "parameters": [
            {
              "name": "course",
              "type": "Course"
            }
          ],
          "returnType": "void",
          "visibility": "public"
        }
      ]
    }
  ],
  "relationships": [
    {
      "id": "enrollment",
      "from": "student",
      "to": "course",
      "type": "association",
      "multiplicity": {
        "from": "1",
        "to": "0..*"
      },
      "name": "enrolls in"
    }
  ]
}

Tool Reference

For detailed API documentation, see the API Reference.

Available Tools

• create_mson_model - Create and validate MSON models from structured data with automatic ID generation and relationship mapping
• validate_mson_model - Validate MSON model consistency and completeness with detailed error messages and relationship validation
• generate_uml_diagram - Generate UML diagrams in PlantUML and Mermaid formats
• export_to_system_designer - Export models to System Designer application format
• create_system_runtime_bundle - Convert MSON models to complete System Runtime bundles with schemas, models, types, behaviors, and components
• validate_system_runtime_bundle - Validate System Runtime bundles for correctness and compatibility

Platform Integration

The server can be integrated with various platforms:

• Claude Desktop - Native MCP integration
• VS Code - Extension development support
• Web Applications - React/Node.js integration
• CLI Tools - Command-line interface

See the Integration Guide for detailed setup instructions.

Architecture

Modular Structure

The codebase follows SOLID principles with clear separation of concerns:

• src/types.ts - TypeScript type definitions for MSON models
• src/schemas.ts - Zod validation schemas for all data structures
• src/tools.ts - MCP tool registration using modern SDK patterns
• src/index.ts - Local MCP server with stdio transport (Node.js/Bun)
• src/worker.ts - Remote MCP server with SSE transport (Cloudflare Workers)
• src/cli.ts - Command-line interface for testing and integration
• src/integration/ - System Designer app integration
• src/transformers/ - MSON to System Runtime transformation logic
• src/validators/ - System Runtime bundle validation logic

Modern MCP SDK Patterns

The server uses the modern MCP TypeScript SDK (v1.18.2) patterns:

1. server.registerTool() - Modern tool registration API (not legacy server.tool())
2. Zod Input Schemas - Type-safe input validation with Zod schema shapes
3. Title Metadata - Each tool includes a title field for better UX
4. Type Inference - Handler methods use Zod-inferred types for parameters

Tool-Based Approach

This server uses a tool-based architecture that:

1. Empowers LLMs: The LLM handles understanding requirements and creating structured data
2. Validates Input: Server validates structured input using comprehensive Zod schemas
3. Processes Efficiently: Simple, fast processing without complex parsing logic
4. Exports Flexibly: Multiple output formats for different use cases

Benefits Over Parser-Based Approaches

• Simplicity: No complex NLP parsing to maintain
• Flexibility: Works with any domain the LLM understands
• Reliability: Fewer moving parts, less error-prone
• Performance: Faster validation and processing
• Extensibility: Easy to add new tools and features

Development

Running Tests

# Run all tests
bun test

# Run tests in watch mode
bun test --watch

Building

# Build for production
bun run build

# Start production server
bun start

Code Structure

src/
├── types.ts                    # TypeScript type definitions for MSON models
├── schemas.ts                  # Zod validation schemas for all data structures
├── tools.ts                    # MCP tool registration using modern SDK patterns
├── index.ts                    # Local MCP server (stdio transport)
├── worker.ts                   # Remote MCP server (SSE transport for Workers)
├── cli.ts                      # Command-line interface
├── integration/
│   └── system-designer.ts     # System Designer app integration
├── transformers/
│   └── system-runtime.ts      # MSON to System Runtime transformation
└── validators/
    └── system-runtime.ts      # System Runtime bundle validation

test/
└── tool-based.test.ts         # Comprehensive test suite

docs/
├── API-REFERENCE.md           # Detailed API documentation
├── CLI-GUIDE.md              # CLI usage guide
├── INTEGRATION-GUIDE.md      # Platform integration guide
└── SYSTEM-RUNTIME-INTEGRATION-GUIDE.md  # System Runtime guide

examples/
├── banking-system.json        # Sample banking system model
├── banking-system-plantuml.puml  # PlantUML output example
├── banking-system-mermaid.md  # Mermaid output example
└── README.md                  # Example documentation

CLOUDFLARE_DEPLOYMENT.md       # Cloudflare Workers deployment guide
test-worker.sh                 # Automated testing script for Workers
wrangler.toml                  # Cloudflare Workers configuration

Integration with System Designer

The server exports models in a format compatible with the System Designer macOS application:

1. File Export: Models are saved as JSON files
2. Automatic Integration: Files can be imported directly into System Designer
3. Format Compatibility: Uses MSON (Metamodel JavaScript Object Notation) format

Recent Changes & Improvements

Latest Updates (v1.0.0)

• 🎯 Critical Bug Fixes (SDMCP-001-005): Resolved property preservation, ID mapping, validation consistency, and bundle compatibility issues
• 🔧 Enhanced Error Messages: Added detailed, actionable error messages with specific fix suggestions and examples
• 🛡️ Relationship Validation: Proactive validation prevents orphaned references with clear guidance
• 🔄 Flexible Input Handling: Support for both 'properties' and 'attributes' in entity definitions
• 📋 Comprehensive Bug Reports: Detailed documentation of all issues and resolutions in docs/BUG_REPORTS.md
• 🆕 System Runtime Tools: Added complete System Runtime bundle creation and validation functionality

Previous Features

• 🏗️ Modular Architecture: Complete refactoring for SOLID principles compliance
• 🧪 Enhanced Testing: 46 tests with 302 assertions covering all functionality including edge cases
• 🚀 Cloudflare Workers Support: Remote MCP server deployment with modern JSON-RPC transport
• 🔄 Modern MCP SDK: Updated to latest MCP TypeScript SDK (v1.18.2) patterns
• 📊 Documentation: Complete API reference, integration guides, and deployment documentation

Contributing

We welcome contributions! Please see our Contributing Guide for details on:

• Setting up the development environment
• Running tests and code quality checks
• Code style guidelines
• Submitting pull requests
• Reporting issues

License

MIT License - see LICENSE file for details.

Acknowledgments

• Model Context Protocol (MCP) for the tool integration framework
• System Designer for the target macOS application
• Zod for type-safe validation
• Bun for the fast JavaScript runtime
