DustCluster v0.2.0 is an AWS command line interface in an REPL shell with cluster-aware ssh and EC2 node operations, with plugin commands to bring up some pre-configured clusters on EC2.
Status:
- Linux and OSX only
- Python 3.x
Quickstart:
Setup your keys in ~/.aws/credentials, as described here
bash$ pip3 install dustcluster
bash$ dust
[eu-west-1] show
- Rationale
- Summary of Features
- More on Filter expressions
- Configure ssh Logins
- Writing plugin commands
- Install
This can be useful for developing, prototyping, and one-off configurations of (usually ephemeral) EC2 clusters. Such as when developing/testing custom data engineering stacks and distributed systems.
-
start/stop/terminate
stop [filter-expression] stop * # stop all nodes stop 1,3,4 # by index stop worker* # by name stop state=running # by EC2 attribute -
list nodes
show [-v] [-vv] [filter-expression | search term] show # list all nodes show -v # list with extended attributes show -vv # list with all attributes show -v 1,3,4 # using filter expresison show -v worker* -
search
$show searches all ec2 attributes and tags show mongo # matches tag app=mongodb show running # matches state=running attribute show 192.168.0.15 # matches public_ip_address, private_ip_address etc show 0.15 # same as above, partial matches work show run -
tag/untag nodes
tag [filter-expression] tags tag worker* env=dev tag 3,4 stack=spark1 -
refresh cache
refresh -
view cloudwatch logs
logs # shows log groups logs /aws/lambda/hello_world # show log streams in this group logs -t /aws/lambda/hello_world # show the most recent log events in this group logs -N 50 -t /aws/lambda/xyz # increase output limit to 50 -
specify AWS credentials profile to work in
dust --profile xyz
Note: Filter expressions can contain index numbers, node names, or all EC2 instance attributes from show -vv .e.g. image=ami-123145. More on filter expressions below.
You need to configure logins first.
-
run non-interactive commands
@[filter-expression] command e.g. Run "uptime" on .. @ uptime # all running nodes @1,3,4 uptime # nodes with indexes 1,3 and 4 @worker* uptime # node names matching worker* @image=ami-1234 uptime # EC2 attribute @tags=key:value uptime # by tags -
run interactive commands
Same as above. This is **stateful** ssh - the connection is kept open. @1,2,3 sudo apt-get install nginx . . [worker3] After this operation, 5,342 kB of additional disk space will be used. [worker3] Do you want to continue? [Y/n] @1,2,3 y // sends a Y to all the nodes named work\* and the apt-get script continues. -
run ncurses/full screen commands
@[filter_exp] - drops to a shell [eu-west-1]$ @9 dust:11:48:43 | *** Entering raw shell, press ctrl-c thrice to return to cluster shell. Press Enter to continue.*** [ec2-user@ip-172-31-44-125 ~]$ [ec2-user@ip-172-31-44-125 ~]$ vim /etc/resolv.conf -
secure copy files
put [filter_exp] localfile* remote_dir get [filter_exp] remotefile local_dir put 1,3 /home/alice/data*.csv /home/ec2-user get 1,3 /home/ec2-user/data3.csv .
When you are working with a 3 node cluster but you have 25 ec2 nodes...
- use a working set
use [clustername | *] use spark1 show # shows cluster nodes only @ uptime # incvoke command over ssh to cluster nodes only tag * cool=yes # tags cluster nodes only
You specify cluster membership in the login configuration.
- remove working set restriction
use *
- Create a N node compute cluster with 10 GBps interconnect with in a placement group in the default VPC, with keys downloaded and security groups configured. More details here.
cluster new - asks for node count and creates a cluster spec
cluster create base1 - converts the spec to a CloudFormation template and instantiates it
cluster status base1 - shows the Cloudformation status
cluster delete base1 - terminates the cluster nodes
use us-east-1 # switch to region
If dustcluster doesn't recognize a command, it drops it to the calling shell.
[eu-west-1]$ ls -plart /var/log
dust:12:06:08 | dustcluster: [ls -plart /var/log] unrecognized, trying system shell...
total 25828
drwx------. 2 root root 4096 Feb 5 2016 ppp/
drwx------. 3 root root 4096 Nov 14 2016 libvirt/
drwxr-xr-x. 2 chrony chrony 4096 Nov 21 2016 chrony/
.
.
[eu-west-1]$ vim /home/alice/topsecret.txt # runs vim locally
- Reverse search (ctrl-R) to retrieve old commands
(reverse-i-search)`':@1,3,5,7 grep -c ERROR /var/logs/applogs/app.log up/down arrow to navigate
Most commands take a target. e.g. show -v [target]
Here, [target] is a comma separated list of filter expressions.
Filter expression can be:
A node index
dust$ stop 1,2,3
dust$ @1,2,3 service restart nginx
By node name
Name comes from Instance tags with Key=Name
dust$ stop worker*
dust$ start wo*
dust$ terminate worker[0-2]
dust$ @worker* vmstat
By EC2 attribute or tags
dust$ show state=stopped
dust$ start state=stop* # filters can have wildcards
dust$ @ip=54.12.* uptime
dust$ @tags=owner:devops uptime
dust$ stop tags=env:* # tags can have wildcards too
dust$ show -v launch_time=2016-04-03*
"show" takes a search term as well so this is equivalent:
dust$ show -v 2016-04-03
By cluster name
dust$ show -v cluster=mystack1
dust$ stop cluster=slurm1
Before using ssh you need to configure logins. Use filter expressions to select nodes with the same login user and key:
i) by using the assign command
This command writes login rules to ~/.dustcluster/login_rules.yaml.
Example:
$assign
selector: tags=key:value
login-user: ec2-user
keyfile : /path/to/kyfile
member-of: webapp
1] selector help:
selector is a filter expression.`
selector: * # selects all nodes
selector: id=0-asd1212 # selects a single node
selector: subnet=s-012sccas # selects all nodes in a subnet
2] member-of help:
member-of adds nodes to a cluster, these nodes are grouped together in "show",
and can be made into a working set with the "use" command. cluster names can be
used in filter expressions.
3] login rules precedence:
login rules are applied in order that they appear in the file.
So given a login_rules.yaml containing:
- selector: tags=env:prod
...
- selector: tags=env:dev
...
- selector: *
...
a command like "@node5 service restart xyz" will search for a login rule by matching prod, dev,
and then default (*) in that order'''
ii) by manually editing the login rules file. See a sample login rules file here.
Write commands to an interface and drop them into dustcluster...
i) Write a plugin command that list all your instances in all regions.
TBD
ii) Write a plugin command that runs a set of ssh commands on a cluster
TBD
If pip install fails on the cryptography libs (needed for ssh), then manually install these deps:
Ubuntu:
# pip
sudo apt-get update
sudo apt-get install python-pip
sudo pip install pip --upgrade
# deps
sudo apt-get install build-essential python-dev libffi-dev libssl-dev
sudo pip install enum34 cffi bcrypt cryptography
# dust
sudo pip3 install dustcluster
AmazonLinux/CentOS:
#deps
yum install gcc gcc-c++ make openssl-devel python-devel libffi-devel libssl-devel
sudo pip install enum34 cffi bcrypt cryptography
# dust
sudo pip3 install dustcluster
