HDR ↔️ SDR Video Converter

A lightweight command-line toolkit for converting video between SDR (Rec.709) and HDR formats (Rec.2100 HLG or PQ). It handles color-space transforms, tone-mapping, transfer functions, and bit-depth conversions with precision. The tool also lets you compare FFmpeg-based and Python-based conversion pipelines, generate test outputs for validation, and create rewrapped files that modify metadata without using transfer functions.

Setup

See .python-version for python version used.

Create a virtual environment:
```
python -m venv .venv
```
or if using uv:
```
uv venv
```
Activate the virtual environment:
```
source .venv/bin/activate
```

Install dependencies from pyproject.toml:

pip install .

or if using uv:

uv sync
# or
uv pip install -r pyproject.toml

Usage

CLI

Run converter:

python main.py <command> -i <path/to/input.mp4> [-o <path/to/output.mp4>]
# or uv
uv run main.py <command> -i <path/to/input.mp4> [-o <path/to/output.mp4>]

List available conversions:

python main.py list
# or uv
uv run main.py list

Commands

sdr2pq, sdr2hlg, pq2sdr, hlg2sdr, pq2hlg, hlg2pq - convert between formats
rewrap — copy pixels and change metadata (use --src and --dst to specify formats)

Formats

sdr — BT.709, 8-bit
pq — BT.2100 PQ (HDR10), 10-bit
hlg — BT.2100 HLG, 10-bit

Default output paths (when -o omitted)

For conversion commands: output/test_<command>.mp4
For rewrap: output/rewrap/test<src>2<dst>rewrapped.mp4

Examples

List commands:

python main.py list
# or uv
uv run main.py list

Convert SDR → HLG:

python main.py sdr2hlg -i test_sdr.mp4
# or uv
uv run main.py sdr2hlg -i test_sdr.mp4

Convert PQ → SDR and write to custom file:

python main.py pq2sdr -i test_pq.mp4 -o ./output/ffmpeg/pq2sdr.mp4
# or uv
uv run main.py pq2sdr -i test_pq.mp4 -o ./output/ffmpeg/pq2sdr.mp4

Rewrap (change metadata):

python main.py rewrap -i test_sdr.mp4 --src sdr --dst hlg
# or uv
uv run main.py rewrap -i test_sdr.mp4 --src sdr --dst hlg

Notes:

Use -o to control the output path; parent directories will be created automatically.
If you rely on ffmpeg in examples, ensure ffmpeg is installed and on PATH.
For reproducible results, keep source/target format metadata consistent with the files you provide.

Test Video Used (test_*.mp4)

HDR PQ Test Video

Download at https://www.demolandia.net/downloads.html?id=654828652
Save as demo_pq.mp4 in the project root directory.
Downscale to 1920x1080 and trim the 32-39 seconds segment for testing:

# need to install ffmpeg first
ffmpeg -i demo_pq.mp4 -vf "fps=30,scale=1920:1080" -ss 32 -to 39 -c:v libx265 -crf 23 -preset fast -tag:v hvc1 -an test_pq.mp4

test_pq.mp4

Check PQ Test Video Details

Video Details from Apple QuickTimePlayer's Video Inspector (Command + I):

Property Value

Bit Depth 10-bit

HDR Type HDR10

Color Primaries ITU-R BT.2020

Transfer Function SMPTE ST 2084 (PQ)

YCbCr Matrix ITU-R BT.2020

or determine the video properties using ffprobe:

ffprobe -v quiet -show_streams -select_streams v:0 -of json test_pq.mp4

Output:

{
  "streams": [
    {
      "index": 0,
      "codec_name": "hevc",
      "codec_long_name": "H.265 / HEVC (High Efficiency Video Coding)",
      "profile": "Main 10",
      "codec_type": "video",
      "codec_tag_string": "hvc1",
      "codec_tag": "0x31637668",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "sample_aspect_ratio": "1:1",
      "display_aspect_ratio": "16:9",
      "pix_fmt": "yuv420p10le",
      "level": 120,
      "color_range": "tv",
      "color_space": "bt2020nc",
      "color_transfer": "smpte2084",
      "color_primaries": "bt2020",
      "chroma_location": "left",
      "field_order": "progressive",
      "refs": 1,
      "view_ids_available": "",
      "view_pos_available": "",
      "id": "0x1",
      "r_frame_rate": "30/1",
      "avg_frame_rate": "30/1",
      "time_base": "1/15360",
      "start_pts": 0,
      "start_time": "0.000000",
      "duration_ts": 107520,
      "duration": "7.000000",
      "bit_rate": "9459573",
      "nb_frames": "210",
      "extradata_size": 2556,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "Video Media Handler",
        "vendor_id": "[0][0][0][0]",
        "encoder": "Lavc62.11.100 libx265"
      },
      "side_data_list": [
        {
          "side_data_type": "Content light level metadata",
          "max_content": 0,
          "max_average": 0
        }
      ]
    }
  ]
}

From the above, we can see that the video is encoded in HDR (10-bit YUV 4:2:0) and uses PQ10 as the transfer function.

HDR HLG Test Video

Save as demo_hlg.mp4 in the project root directory.
Trim the 29-32 seconds segment for testing:

# need to install ffmpeg first
ffmpeg -i test_hlg.mp4 -ss 29 -to 32 -c:v libx265 -crf 23 -preset fast -tag:v hvc1 test_hlg.mp4

test_hlg.mp4

Check HLG Test Video Details

Video Details from Apple QuickTimePlayer's Video Inspector (Command + I):

Property Value

Bit Depth 10-bit

HDR Type HLG

Color Primaries ITU-R BT.2020

Transfer Function SMPTE ST 2100 (HLG)

YCbCr Matrix ITU-R BT.2020

or determine the video properties using ffprobe:

ffprobe -v quiet -show_streams -select_streams v:0 -of json test_hlg.mp4

Output:

{
  "streams": [
    {
      "index": 0,
      "codec_name": "hevc",
      "codec_long_name": "H.265 / HEVC (High Efficiency Video Coding)",
      "profile": "Main 10",
      "codec_type": "video",
      "codec_tag_string": "hvc1",
      "codec_tag": "0x31637668",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "sample_aspect_ratio": "1:1",
      "display_aspect_ratio": "16:9",
      "pix_fmt": "yuv420p10le",
      "level": 120,
      "color_range": "tv",
      "color_space": "bt2020nc",
      "color_transfer": "arib-std-b67",
      "color_primaries": "bt2020",
      "chroma_location": "left",
      "field_order": "progressive",
      "refs": 1,
      "view_ids_available": "",
      "view_pos_available": "",
      "id": "0x1",
      "r_frame_rate": "30000/1001",
      "avg_frame_rate": "30000/1001",
      "time_base": "1/30000",
      "start_pts": 990,
      "start_time": "0.033000",
      "duration_ts": 89089,
      "duration": "2.969633",
      "bit_rate": "2642966",
      "nb_frames": "89",
      "extradata_size": 2595,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "eng",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]",
        "encoder": "Lavc62.11.100 libx265"
      },
      "side_data_list": [
        {
          "side_data_type": "Mastering display metadata",
          "red_x": "34000/50000",
          "red_y": "16000/50000",
          "green_x": "13248/50000",
          "green_y": "34500/50000",
          "blue_x": "7500/50000",
          "blue_y": "3000/50000",
          "white_point_x": "15634/50000",
          "white_point_y": "16450/50000",
          "min_luminance": "50/10000",
          "max_luminance": "10000000/10000"
        },
        {
          "side_data_type": "Content light level metadata",
          "max_content": 0,
          "max_average": 0
        }
      ]
    }
  ]
}

From the above, we can see that the video is encoded in HDR (10-bit YUV 4:2:0) and uses HLG as the transfer function.

SDR Test Video

test_sdr.mp4

Download Big Buck Bunny from https://test-videos.co.uk/vids/bigbuckbunny/mp4/h264/1080/Big_Buck_Bunny_1080_10s_1MB.mp4
Save as test_sdr.mp4 in the project root directory.

Check HLG Test Video Details

Determine the video properties using ffprobe:

ffprobe -v quiet -show_streams -select_streams v:0 -of json test_sdr.mp4

Output:

{
  "streams": [
    {
      "index": 0,
      "codec_name": "h264",
      "codec_long_name": "H.264 / AVC / MPEG-4 AVC / MPEG-4 part 10",
      "profile": "High",
      "codec_type": "video",
      "codec_tag_string": "avc1",
      "codec_tag": "0x31637661",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "sample_aspect_ratio": "1:1",
      "display_aspect_ratio": "16:9",
      "pix_fmt": "yuv420p",
      "level": 51,
      "chroma_location": "left",
      "field_order": "progressive",
      "refs": 1,
      "is_avc": "true",
      "nal_length_size": "4",
      "id": "0x1",
      "r_frame_rate": "30/1",
      "avg_frame_rate": "30/1",
      "time_base": "1/15360",
      "start_pts": 0,
      "start_time": "0.000000",
      "duration_ts": 153600,
      "duration": "10.000000",
      "bit_rate": "24559867",
      "bits_per_raw_sample": "8",
      "nb_frames": "300",
      "extradata_size": 47,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

From the above, we can see that the video is encoded in SDR (8-bit YUV 4:2:0).

Results

The converted videos are saved in the output/ directory:

HDR (PQ10) ➡️ SDR Conversion

output/ffmpeg/pq2sdr.mp4: Converted to SDR using ffmpeg command:
```
ffmpeg -i test_pq.mp4 -vf "zscale=t=linear:npl=100, format=gbrpf32le, zscale=p=bt709, zscale=t=bt709:m=bt709:r=tv, format=yuv420p" ./output/ffmpeg/pq2sdr.mp4
```
Video Details from Apple QuickTimePlayer's Video Inspector (Command + I):

Property Value

Color Primaries ITU-R BT.709

Transfer Function ITU-R BT.709

YCbCr Matrix ITU-R BT.709

output/test_pq2sdr.mp4: Converted using main.py command:

python main.py pq2sdr -i test_pq.mp4
# or using uv
uv run main.py pq2sdr -i test_pq.mp4

Video Details using ffprobe (same as above command just diff file):

{
  "streams": [
    {
      "index": 0,
      "codec_name": "h264",
      "codec_long_name": "H.264 / AVC / MPEG-4 AVC / MPEG-4 part 10",
      "profile": "High",
      "codec_type": "video",
      "codec_tag_string": "avc1",
      "codec_tag": "0x31637661",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "pix_fmt": "yuv420p",
      "level": 40,
      "color_range": "tv",
      "color_space": "bt709",
      "color_transfer": "bt709",
      "color_primaries": "bt709",
      "chroma_location": "left",
      "field_order": "progressive",
      "refs": 1,
      "is_avc": "true",
      "nal_length_size": "4",
      "id": "0x1",
      "r_frame_rate": "30/1",
      "avg_frame_rate": "30/1",
      "time_base": "1/15360",
      "start_pts": 0,
      "start_time": "0.000000",
      "duration_ts": 107520,
      "duration": "7.000000",
      "bit_rate": "24181306",
      "bits_per_raw_sample": "8",
      "nb_frames": "210",
      "extradata_size": 50,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

output/rewrap/test_pq2sdr_rewrapped.mp4: Rewrap (convert without using transfer functions, changed metadata) using main.py command:

python main.py rewrap -i test_pq.mp4 --src pq --dst sdr
# or using uv
uv run main.py rewrap -i test_pq.mp4 --src pq --dst sdr

Video Details using ffprobe (same as above command just diff file):

{
  "streams": [
    {
      "index": 0,
      "codec_name": "h264",
      "codec_long_name": "H.264 / AVC / MPEG-4 AVC / MPEG-4 part 10",
      "profile": "High",
      "codec_type": "video",
      "codec_tag_string": "avc1",
      "codec_tag": "0x31637661",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "pix_fmt": "yuv420p",
      "level": 40,
      "color_range": "tv",
      "color_space": "bt709",
      "color_transfer": "bt709",
      "color_primaries": "bt709",
      "chroma_location": "left",
      "field_order": "progressive",
      "refs": 1,
      "is_avc": "true",
      "nal_length_size": "4",
      "id": "0x1",
      "r_frame_rate": "30/1",
      "avg_frame_rate": "30/1",
      "time_base": "1/15360",
      "start_pts": 0,
      "start_time": "0.000000",
      "duration_ts": 107520,
      "duration": "7.000000",
      "bit_rate": "15408329",
      "bits_per_raw_sample": "8",
      "nb_frames": "210",
      "extradata_size": 50,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

Comparison

Original HDR PQ	Converted SDR using ffmpeg	Converted SDR using main.py	Rewrapped SDR using main.py
test_pq.mp4	pq2sdr.mp4	test_pq2sdr.mp4	test_pq2sdr_rewrapped.mp4

HDR (PQ10) ➡️ HDR (HLG) Conversion

output/ffmpeg/pq2hlg.mp4: Converted to HLG using ffmpeg command:
```
ffmpeg -i test.mp4 -vf "zscale=t=arib-std-b67" -c:v libx265 -crf 20 -preset fast -tag:v hvc1 ./output/ffmpeg/pq2hlg.mp4
```
Video Details from Apple QuickTimePlayer's Video Inspector (Command + I):

Property Value

Bit Depth 10-bit

HDR Type HLG

Color Primaries ITU-R BT.2020

Transfer Function SMPTE ST 2100 (HLG)

YCbCr Matrix ITU-R BT.2020

output/test_pq2hlg.mp4: Converted using main.py command:

python main.py pq2hlg -i test_pq.mp4
# or using uv
uv run main.py pq2hlg -i test_pq.mp4

Video Details using ffprobe (same as above command just diff file):

{
  "streams": [
    {
      "index": 0,
      "codec_name": "hevc",
      "codec_long_name": "H.265 / HEVC (High Efficiency Video Coding)",
      "profile": "Main 10",
      "codec_type": "video",
      "codec_tag_string": "hvc1",
      "codec_tag": "0x31637668",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "pix_fmt": "yuv420p10le",
      "level": 120,
      "color_range": "tv",
      "color_space": "bt2020nc",
      "color_transfer": "arib-std-b67",
      "color_primaries": "bt2020",
      "chroma_location": "left",
      "refs": 1,
      "view_ids_available": "",
      "view_pos_available": "",
      "id": "0x1",
      "r_frame_rate": "30/1",
      "avg_frame_rate": "30/1",
      "time_base": "1/15360",
      "start_pts": 0,
      "start_time": "0.000000",
      "duration_ts": 107520,
      "duration": "7.000000",
      "bit_rate": "12564515",
      "nb_frames": "210",
      "extradata_size": 2438,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

output/rewrap/test_pq2hlg_rewrapped.mp4: Rewrap (convert without using transfer functions, changed metadata) using main.py command:

python main.py rewrap -i test_pq.mp4 --src pq --dst hlg
# or using uv
uv run main.py rewrap -i test_pq.mp4 --src pq --dst hlg

Video Details using ffprobe (same as above command just diff file):

{
  "streams": [
    {
      "index": 0,
      "codec_name": "hevc",
      "codec_long_name": "H.265 / HEVC (High Efficiency Video Coding)",
      "profile": "Main 10",
      "codec_type": "video",
      "codec_tag_string": "hvc1",
      "codec_tag": "0x31637668",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "pix_fmt": "yuv420p10le",
      "level": 120,
      "color_range": "tv",
      "color_space": "bt2020nc",
      "color_transfer": "arib-std-b67",
      "color_primaries": "bt2020",
      "chroma_location": "left",
      "refs": 1,
      "view_ids_available": "",
      "view_pos_available": "",
      "id": "0x1",
      "r_frame_rate": "30/1",
      "avg_frame_rate": "30/1",
      "time_base": "1/15360",
      "start_pts": 0,
      "start_time": "0.000000",
      "duration_ts": 107520,
      "duration": "7.000000",
      "bit_rate": "10413285",
      "nb_frames": "210",
      "extradata_size": 2438,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

Comparison

Original HDR PQ	Converted HLG using ffmpeg	Converted HLG using main.py	Rewrapped HLG using main.py
test_pq.mp4	pq2hlg.mp4	test_pq2hlg.mp4	test_pq2hlg_rewrapped.mp4

HDR (HLG) ➡️ SDR Conversion

output/ffmpeg/hlg2sdr.mp4: Converted to SDR using ffmpeg command:
```
ffmpeg -i test_hlg.mp4 -vf "zscale=t=linear:npl=100, format=gbrpf32le, zscale=p=bt709, zscale=t=bt709:m=bt709:r=tv, format=yuv420p" ./output/ffmpeg/hlg2sdr.mp4
```
Video Details from Apple QuickTimePlayer's Video Inspector (Command + I):

Property Value

Color Primaries ITU-R BT.709

Transfer Function ITU-R BT.709

YCbCr Matrix ITU-R BT.709

output/test_hlg2sdr.mp4: Converted using main.py command:

python main.py hlg2sdr -i test_hlg.mp4
# or using uv
uv run main.py hlg2sdr -i test_hlg.mp4

Video Details using ffprobe (same as above command just diff file):

{
  "streams": [
    {
      "index": 0,
      "codec_name": "h264",
      "codec_long_name": "H.264 / AVC / MPEG-4 AVC / MPEG-4 part 10",
      "profile": "High",
      "codec_type": "video",
      "codec_tag_string": "avc1",
      "codec_tag": "0x31637661",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "pix_fmt": "yuv420p",
      "level": 40,
      "color_range": "tv",
      "color_space": "bt709",
      "color_transfer": "bt709",
      "color_primaries": "bt709",
      "chroma_location": "left",
      "field_order": "progressive",
      "refs": 1,
      "is_avc": "true",
      "nal_length_size": "4",
      "id": "0x1",
      "r_frame_rate": "30000/1001",
      "avg_frame_rate": "30000/1001",
      "time_base": "1/30000",
      "start_pts": 990,
      "start_time": "0.033000",
      "duration_ts": 89089,
      "duration": "2.969633",
      "bit_rate": "6882767",
      "bits_per_raw_sample": "8",
      "nb_frames": "89",
      "extradata_size": 49,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

output/rewrap/test_hlg2sdr_rewrapped.mp4: Rewrap (convert without using transfer functions, changed metadata) using main.py command:

python main.py rewrap -i test_hlg.mp4 --src hlg --dst sdr
# or using uv
uv run main.py rewrap -i test_hlg.mp4 --src hlg --dst sdr

Video Details using ffprobe (same as above command just diff file):

{
  "streams": [
    {
      "index": 0,
      "codec_name": "h264",
      "codec_long_name": "H.264 / AVC / MPEG-4 AVC / MPEG-4 part 10",
      "profile": "High",
      "codec_type": "video",
      "codec_tag_string": "avc1",
      "codec_tag": "0x31637661",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "pix_fmt": "yuv420p",
      "level": 40,
      "color_range": "tv",
      "color_space": "bt709",
      "color_transfer": "bt709",
      "color_primaries": "bt709",
      "chroma_location": "left",
      "field_order": "progressive",
      "refs": 1,
      "is_avc": "true",
      "nal_length_size": "4",
      "id": "0x1",
      "r_frame_rate": "30000/1001",
      "avg_frame_rate": "30000/1001",
      "time_base": "1/30000",
      "start_pts": 990,
      "start_time": "0.033000",
      "duration_ts": 89089,
      "duration": "2.969633",
      "bit_rate": "4849657",
      "bits_per_raw_sample": "8",
      "nb_frames": "89",
      "extradata_size": 49,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

Comparison

Original HDR HLG	Converted SDR using ffmpeg	Converted SDR using main.py	Rewrap SDR using main.py
test_hlg.mp4	hlg2sdr.mp4	test_hlg2sdr.mp4	test_hlg2sdr_rewrapped.mp4

HDR (HLG) ➡️ HDR (PQ10) Conversion

output/ffmpeg/hlg2pq.mp4: Converted to HDR (PQ10) using ffmpeg command:
```
ffmpeg -i test_hlg.mp4 -vf "zscale=t=smpte2084" -c:v libx265 -crf 20 -preset fast -tag:v hvc1 ./output/ffmpeg/hlg2pq.mp4
```
Video Details from Apple QuickTimePlayer's Video Inspector (Command + I):

Property Value

Bit Depth 10-bit

HDR Type HDR10

Color Primaries ITU-R BT.2020

Transfer Function SMPTE ST 2084 (PQ)

YCbCr Matrix ITU-R BT.2020

output/test_hlg2pq.mp4: Converted using main.py command:

python main.py hlg2pq -i test_hlg.mp4
# or using uv
uv run main.py hlg2pq -i test_hlg.mp4

Video Details using ffprobe (same as above command just diff file):

{
  "streams": [
    {
      "index": 0,
      "codec_name": "hevc",
      "codec_long_name": "H.265 / HEVC (High Efficiency Video Coding)",
      "profile": "Main 10",
      "codec_type": "video",
      "codec_tag_string": "hvc1",
      "codec_tag": "0x31637668",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "pix_fmt": "yuv420p10le",
      "level": 120,
      "color_range": "tv",
      "color_space": "bt2020nc",
      "color_transfer": "smpte2084",
      "color_primaries": "bt2020",
      "chroma_location": "left",
      "refs": 1,
      "view_ids_available": "",
      "view_pos_available": "",
      "id": "0x1",
      "r_frame_rate": "30000/1001",
      "avg_frame_rate": "30000/1001",
      "time_base": "1/30000",
      "start_pts": 990,
      "start_time": "0.033000",
      "duration_ts": 89089,
      "duration": "2.969633",
      "bit_rate": "2574192",
      "nb_frames": "89",
      "extradata_size": 2442,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

output/rewrap/test_hlg2pq_rewrapped.mp4: Rewrap (convert without using transfer functions, changed metadata) using main.py command:

python main.py rewrap -i test_hlg.mp4 --src hlg --dst pq
# or using uv
uv run main.py rewrap -i test_hlg.mp4 --src hlg --dst pq

Video Details using ffprobe (same as above command just diff file):

{
  "streams": [
    {
      "index": 0,
      "codec_name": "hevc",
      "codec_long_name": "H.265 / HEVC (High Efficiency Video Coding)",
      "profile": "Main 10",
      "codec_type": "video",
      "codec_tag_string": "hvc1",
      "codec_tag": "0x31637668",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "pix_fmt": "yuv420p10le",
      "level": 120,
      "color_range": "tv",
      "color_space": "bt2020nc",
      "color_transfer": "smpte2084",
      "color_primaries": "bt2020",
      "chroma_location": "left",
      "refs": 1,
      "view_ids_available": "",
      "view_pos_available": "",
      "id": "0x1",
      "r_frame_rate": "30000/1001",
      "avg_frame_rate": "30000/1001",
      "time_base": "1/30000",
      "start_pts": 990,
      "start_time": "0.033000",
      "duration_ts": 89089,
      "duration": "2.969633",
      "bit_rate": "2855908",
      "nb_frames": "89",
      "extradata_size": 2442,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

Comparison

Original HDR HLG	Converted PQ using ffmpeg	Converted PQ using main.py	Rewrapped PQ using main.py
test_hlg.mp4	hlg2pq.mp4	test_hlg2pq.mp4	test_hlg2pq_rewrapped.mp4

SDR ➡️ HDR (PQ10) Conversion

output/ffmpeg/sdr2pq.mp4: Converted to HDR (PQ10) using ffmpeg command:
```
ffmpeg -i "test_sdr.mp4" -vf "format=gbrpf32le, zscale=tin=bt709:pin=bt709:t=smpte2084:p=bt2020:m=bt2020nc, format=yuv420p10le" -c:v libx265 -crf 20 -preset fast -tag:v hvc1 ./output/ffmpeg/sdr2pq.mp4
```
Video Details from Apple QuickTimePlayer's Video Inspector (Command + I):

Property Value

Bit Depth 10-bit

HDR Type HDR10

Color Primaries ITU-R BT.2020

Transfer Function SMPTE ST 2084 (PQ)

YCbCr Matrix ITU-R BT.2020

output/test_sdr2pq.mp4: Converted using main.py command:

python main.py sdr2pq -i test_sdr.mp4
# or using uv
uv run main.py sdr2pq -i test_sdr.mp4

Video Details using ffprobe (same as above command just diff file):

{
  "streams": [
    {
      "index": 0,
      "codec_name": "hevc",
      "codec_long_name": "H.265 / HEVC (High Efficiency Video Coding)",
      "profile": "Main 10",
      "codec_type": "video",
      "codec_tag_string": "hvc1",
      "codec_tag": "0x31637668",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "pix_fmt": "yuv420p10le",
      "level": 120,
      "color_range": "tv",
      "color_space": "bt2020nc",
      "color_transfer": "smpte2084",
      "color_primaries": "bt2020",
      "chroma_location": "left",
      "refs": 1,
      "view_ids_available": "",
      "view_pos_available": "",
      "id": "0x1",
      "r_frame_rate": "30/1",
      "avg_frame_rate": "30/1",
      "time_base": "1/15360",
      "start_pts": 0,
      "start_time": "0.000000",
      "duration_ts": 153600,
      "duration": "10.000000",
      "bit_rate": "4456511",
      "nb_frames": "300",
      "extradata_size": 2438,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

output/rewrap/test_sdr2pq_rewrapped.mp4: Rewrap (convert without using transfer functions, changed metadata) using main.py command:

python main.py rewrap -i test_sdr.mp4 --src sdr --dst pq
# or using uv
uv run main.py rewrap -i test_sdr.mp4 --src sdr --dst pq

Video Details using ffprobe (same as above command just diff file):

{
  "streams": [
    {
      "index": 0,
      "codec_name": "hevc",
      "codec_long_name": "H.265 / HEVC (High Efficiency Video Coding)",
      "profile": "Main 10",
      "codec_type": "video",
      "codec_tag_string": "hvc1",
      "codec_tag": "0x31637668",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "pix_fmt": "yuv420p10le",
      "level": 120,
      "color_range": "tv",
      "color_space": "bt2020nc",
      "color_transfer": "smpte2084",
      "color_primaries": "bt2020",
      "chroma_location": "left",
      "refs": 1,
      "view_ids_available": "",
      "view_pos_available": "",
      "id": "0x1",
      "r_frame_rate": "30/1",
      "avg_frame_rate": "30/1",
      "time_base": "1/15360",
      "start_pts": 0,
      "start_time": "0.000000",
      "duration_ts": 153600,
      "duration": "10.000000",
      "bit_rate": "7674006",
      "nb_frames": "300",
      "extradata_size": 2438,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

Comparison

Original SDR	Converted PQ using ffmpeg	Converted PQ using main.py	Rewrapped PQ using main.py
test_sdr.mp4	sdr2pq.mp4	test_sdr2pq.mp4	test_sdr2pq_rewrapped.mp4

SDR ➡️ HDR (HLG) Conversion

output/ffmpeg/sdr2hlg.mp4: Converted to HDR (HLG) using ffmpeg command:
```
ffmpeg -i "test_sdr.mp4" -vf "format=gbrpf32le, zscale=tin=bt709:pin=bt709:t=arib-std-b67:p=bt2020:m=bt2020nc, format=yuv420p10le" -c:v libx265 -crf 20 -preset fast -tag:v hvc1 ./output/ffmpeg/sdr2hlg.mp4
```
Video Details from Apple QuickTimePlayer's Video Inspector (Command + I):

Property Value

Bit Depth 10-bit

HDR Type HLG

Color Primaries ITU-R BT.2020

Transfer Function ITU-R BT.2100 HLG

YCbCr Matrix ITU-R BT.2020

output/test_sdr2hlg.mp4: Converted using main.py command:

python main.py sdr2hlg -i test_sdr.mp4
# or using uv
uv run main.py sdr2hlg -i test_sdr.mp4

Video Details using ffprobe (same as above command just diff file):

{
  "streams": [
    {
      "index": 0,
      "codec_name": "hevc",
      "codec_long_name": "H.265 / HEVC (High Efficiency Video Coding)",
      "profile": "Main 10",
      "codec_type": "video",
      "codec_tag_string": "hvc1",
      "codec_tag": "0x31637668",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "pix_fmt": "yuv420p10le",
      "level": 120,
      "color_range": "tv",
      "color_space": "bt2020nc",
      "color_transfer": "arib-std-b67",
      "color_primaries": "bt2020",
      "chroma_location": "left",
      "refs": 1,
      "view_ids_available": "",
      "view_pos_available": "",
      "id": "0x1",
      "r_frame_rate": "30/1",
      "avg_frame_rate": "30/1",
      "time_base": "1/15360",
      "start_pts": 0,
      "start_time": "0.000000",
      "duration_ts": 153600,
      "duration": "10.000000",
      "bit_rate": "5601019",
      "nb_frames": "300",
      "extradata_size": 2438,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

output/rewrap/test_sdr2hlg_rewrapped.mp4: Rewrap (convert without using transfer functions, changed metadata) using main.py command:

python main.py rewrap -i test_sdr.mp4 --src sdr --dst hlg
# or using uv
uv run main.py rewrap -i test_sdr.mp4 --src sdr --dst hlg

Video Details using ffprobe (same as above command just diff file):

{
  "streams": [
    {
      "index": 0,
      "codec_name": "hevc",
      "codec_long_name": "H.265 / HEVC (High Efficiency Video Coding)",
      "profile": "Main 10",
      "codec_type": "video",
      "codec_tag_string": "hvc1",
      "codec_tag": "0x31637668",
      "width": 1920,
      "height": 1080,
      "coded_width": 1920,
      "coded_height": 1080,
      "has_b_frames": 2,
      "pix_fmt": "yuv420p10le",
      "level": 120,
      "color_range": "tv",
      "color_space": "bt2020nc",
      "color_transfer": "arib-std-b67",
      "color_primaries": "bt2020",
      "chroma_location": "left",
      "refs": 1,
      "view_ids_available": "",
      "view_pos_available": "",
      "id": "0x1",
      "r_frame_rate": "30/1",
      "avg_frame_rate": "30/1",
      "time_base": "1/15360",
      "start_pts": 0,
      "start_time": "0.000000",
      "duration_ts": 153600,
      "duration": "10.000000",
      "bit_rate": "7674006",
      "nb_frames": "300",
      "extradata_size": 2438,
      "disposition": {
        "default": 1,
        "dub": 0,
        "original": 0,
        "comment": 0,
        "lyrics": 0,
        "karaoke": 0,
        "forced": 0,
        "hearing_impaired": 0,
        "visual_impaired": 0,
        "clean_effects": 0,
        "attached_pic": 0,
        "timed_thumbnails": 0,
        "non_diegetic": 0,
        "captions": 0,
        "descriptions": 0,
        "metadata": 0,
        "dependent": 0,
        "still_image": 0,
        "multilayer": 0
      },
      "tags": {
        "language": "und",
        "handler_name": "VideoHandler",
        "vendor_id": "[0][0][0][0]"
      }
    }
  ]
}

Comparison

Original SDR	Converted HLG using ffmpeg	Converted HLG using main.py	Rewrapped HLG using main.py
test_sdr.mp4	sdr2hlg.mp4	test_sdr2hlg.mp4	test_sdr2hlg_rewrapped.mp4

References

https://www.itu.int/rec/R-REC-BT.2100-3-202502-I/en

https://www.itu.int/rec/R-REC-BT.709-6-201506-I/en

https://www.itu.int/rec/R-REC-BT.1886-0-201103-I/en

https://www.itu.int/rec/R-REC-BT.2087/en

https://www.itu.int/rec/R-REC-BT.2020-2-201510-I/en

https://www.itu.int/pub/R-REP-BT.2408-8-2024

Provide feedback

Saved searches

Use saved searches to filter your results more quickly

Uh oh!

Repository files navigation

HDR ↔️ SDR Video Converter

Setup

Usage

Test Video Used (test_*.mp4)

HDR PQ Test Video

HDR HLG Test Video

SDR Test Video

Results

References

About

Uh oh!

Releases

Packages

Uh oh!

Languages

Name		Name	Last commit message	Last commit date
Latest commit History 14 Commits
converter		converter
output		output
utils		utils
.gitignore		.gitignore
.python-version		.python-version
README.md		README.md
main.py		main.py
pyproject.toml		pyproject.toml
test_hlg.mp4		test_hlg.mp4
test_pq.mp4		test_pq.mp4
test_sdr.mp4		test_sdr.mp4
uv.lock		uv.lock

Property	Value
Bit Depth	10-bit
HDR Type	HDR10
Color Primaries	ITU-R BT.2020
Transfer Function	SMPTE ST 2084 (PQ)
YCbCr Matrix	ITU-R BT.2020

Property	Value
Color Primaries	ITU-R BT.709
Transfer Function	ITU-R BT.709
YCbCr Matrix	ITU-R BT.709

andrewhsugithub/hdr-sdr-converter

Folders and files

Latest commit

History

Repository files navigation

HDR ↔️ SDR Video Converter

Setup

Usage

Test Video Used (test_*.mp4)

HDR PQ Test Video

HDR HLG Test Video

SDR Test Video

Results

References

About

Topics

Resources

Uh oh!

Stars

Watchers

Forks

Releases

Packages 0

Uh oh!

Languages

Packages
