Skyflow for Databricks: Unity Catalog PII & Sensitive Data Protection

This solution provides secure data tokenization and detokenization capabilities in Databricks Unity Catalog to protect PII and other sensitive data using Skyflow's Data Privacy Vault services. Built with pure SQL UDFs using Unity Catalog HTTP connections for maximum performance and seamless integration with column-level security.

Table of Contents

• Quick Start
• Architecture
  • Flow Overview
  • Key Components
• Configuration
  • Prerequisites
  • Databricks Permissions Required
  • Project Structure
  • Environment Variables (.env.local)
• Development
  • Adding New PII Columns
  • CLI Features
  • Dashboard Integration
  • Cleanup

Demo

A demonstration of this solution was featured in the 'From PII to GenAI: Architecting for Data Privacy & Security in 2025' webinar.

Quick Start

1. Clone and Configure:

   git clone <repository>
   cd Databricks
   cp .env.local.example .env.local

2. Set Environment Variables - Edit .env.local with your credentials:

   # Databricks Configuration
   DATABRICKS_SERVER_HOSTNAME=your-workspace.cloud.databricks.com
   DATABRICKS_PAT_TOKEN=dapi123...your-pat-token
   DATABRICKS_HTTP_PATH=/sql/1.0/warehouses/your-warehouse-id

   # Skyflow Configuration
   SKYFLOW_VAULT_URL=https://your-vault-url
   SKYFLOW_PAT_TOKEN=eyJhbGci...your-pat-token
   SKYFLOW_VAULT_ID=your-vault-id

3. Install Dependencies & Deploy:

   pip install -r requirements.txt
   python setup.py create demo

   This creates:

   • ✅ Unity Catalog: demo_catalog
   • ✅ Sample table with tokenized records
   • ✅ UC connections and secrets
   • ✅ Pure SQL detokenization functions
   • ✅ Column masks on 6 PII columns with role-based access
   • ✅ Customer insights dashboard

4. Test Role-Based Access:

   -- Query returns different results based on your role
   SELECT first_name, last_name, email, phone_number FROM demo_catalog.default.demo_customer_data LIMIT 3;

   -- Check your group membership
   SELECT
       current_user() AS user,
       is_account_group_member('auditor') AS is_auditor,
       is_account_group_member('customer_service') AS is_customer_service,
       is_account_group_member('marketing') AS is_marketing;

Key Benefits

• 🚀 Pure SQL Performance: Unity Catalog HTTP connections with zero Python overhead
• 🔒 Role-Based Security: Automatic data masking via Unity Catalog column masks
• ⚡ Serverless Ready: Designed for Databricks serverless compute environments
• 🔧 Easy Integration: Native Unity Catalog functions work with any SQL client
• 📊 Real-time Access Control: Instant role-based access via is_account_group_member()
• 🛡️ Graceful Error Handling: Returns tokens on API failures to ensure data availability

Role-Based Data Access

The solution supports three role-based access levels:

Role	Group	Data Visibility	Example Output
Auditor	auditor	Plain text (detokenized)	Jonathan
Customer Service	customer_service	Masked (partial hiding)	J****an
Marketing	marketing	Token (no access)	4532-8765-9abc-def0

Column Mask Behavior

-- Same query, different results based on role:
SELECT customer_id, first_name, email FROM demo_catalog.default.demo_customer_data LIMIT 1;

-- Auditor sees:        CUST00001 | Jonathan | jonathan.anderson@example.com
-- Customer Service:    CUST00001 | J****an  | j****an.a*****on@example.com
-- Marketing:           CUST00001 | 4532-8765... | 9876-5432-abcd...

Role Propagation: After changing user roles, Databricks may take 1-2 minutes to propagate changes.

Architecture

Flow Overview

sequenceDiagram
    participant Client as SQL Client
    participant UC as Unity Catalog
    participant UDF as Detokenize UDF
    participant SF as Skyflow API

    Client->>UC: SELECT first_name, email FROM customer_data
    UC->>UC: Check column mask policy
    UC->>UDF: Call detokenization function
    UDF->>UDF: Check is_account_group_member()

    alt User is auditor
        UDF->>SF: POST /detokenize via UC connection
        SF-->>UDF: Return plain text value
        UDF-->>UC: Return detokenized data
    else User is customer_service
        UDF-->>UC: Return masked data (no API call)
    else User is other role
        UDF-->>UC: Return token (no API call)
    end

    UC-->>Client: Return appropriate data

Loading

Key Components

• Unity Catalog Connection: skyflow_conn → /v1/vaults/{vault_id} (unified endpoint)
• Role-based UDF: {prefix}_skyflow_conditional_detokenize() - handles all role logic
• Column Mask UDF: {prefix}_skyflow_mask_detokenize() - applied at table schema level

Python CLI Usage

# Create integration
python setup.py create demo

# Verify integration
python setup.py verify demo

# Destroy integration
python setup.py destroy demo

# Get help
python setup.py --help

Configuration

Prerequisites

1. Databricks Unity Catalog with account-level groups configured
2. Skyflow Account with valid PAT token and configured vault

Databricks Permissions Required

The user running this solution needs the following Databricks permissions:

Account-Level Permissions

• Account Admin OR Metastore Admin (to create catalogs and manage Unity Catalog resources)

Workspace-Level Permissions

Permission	Purpose	Required For
Create Cluster/SQL Warehouse	Job execution	Tokenization notebook runs
Manage Secrets	Secret scope management	Creating skyflow-secrets scope
Workspace Admin	Resource management	Creating notebooks, dashboards

Unity Catalog Permissions

Resource	Permission	Purpose
Metastore	CREATE CATALOG	Creating {prefix}_catalog
Catalog	USE CATALOG, CREATE SCHEMA	Schema and table creation
Schema	USE SCHEMA, CREATE TABLE, CREATE FUNCTION	Table and UDF creation
External Locations	CREATE CONNECTION	HTTP connections for Skyflow API

Required Account Groups

The solution references these account-level groups (create before deployment):

• auditor - Users who see detokenized (plain text) data
• customer_service - Users who see masked data (e.g., J****an)
• marketing - Users who see only tokens

PAT Token Permissions

Your Databricks PAT token must have:

• Workspace access (read/write)
• Unity Catalog access (manage catalogs, schemas, functions)
• SQL Warehouse access (execute statements)
• Secrets management (create/manage secret scopes)

Minimum Setup Command

# Grant necessary permissions (run as Account Admin)
databricks account groups create --display-name "auditor"
databricks account groups create --display-name "customer_service"
databricks account groups create --display-name "marketing"

# Add users to appropriate groups
databricks account groups add-member --group-name "auditor" --user-name "user@company.com"

Permission Validation

Test your permissions before deployment:

# Test configuration and permissions
python setup.py config-test

# This validates:
# - PAT token authentication
# - Unity Catalog access
# - SQL Warehouse connectivity
# - Required file permissions

Common Permission Issues

Error	Cause	Solution
PERMISSION_DENIED: User does not have CREATE CATALOG	Missing metastore admin rights	Grant Metastore Admin or Account Admin
INVALID_STATE: Cannot create secret scope	Missing secrets permissions	Grant Manage permission on workspace secrets
PERMISSION_DENIED: CREATE CONNECTION	Missing connection permissions	Ensure Unity Catalog CREATE CONNECTION permission
Group 'auditor' not found	Missing account groups	Create account-level groups first

Project Structure

skyflow_databricks/          # Main Python package
├── cli/                     # CLI commands
├── config/                  # Configuration management
├── databricks_ops/          # Databricks SDK operations
├── utils/                   # Utility functions
└── templates/               # Deployment templates
    ├── sql/                 # SQL definitions (setup/destroy/verify)
    ├── notebooks/           # Serverless tokenization notebook
    └── dashboards/          # Pre-built analytics dashboard

Environment Variables (.env.local)

# Databricks Connection
DATABRICKS_SERVER_HOSTNAME=your-workspace.cloud.databricks.com
DATABRICKS_PAT_TOKEN=dapi123...
DATABRICKS_HTTP_PATH=/sql/1.0/warehouses/your-warehouse-id

# Skyflow Integration
SKYFLOW_VAULT_URL=https://your-vault.vault.skyflowapis.com
SKYFLOW_VAULT_ID=your-vault-id
SKYFLOW_PAT_TOKEN=eyJhbGci...your-pat-token
SKYFLOW_TABLE=pii
SKYFLOW_TABLE_COLUMN=pii_values
SKYFLOW_BATCH_SIZE=25

# Role Mappings (used by functions)
PLAIN_TEXT_GROUPS=auditor           # See real data
MASKED_GROUPS=customer_service      # See masked data (e.g., J****an)
REDACTED_GROUPS=marketing           # See tokens only

Unity Catalog Setup

The solution creates these UC resources:

• Secrets Scope: skyflow-secrets (UC-backed)
• HTTP Connection: skyflow_conn (unified connection)
• Catalog: {prefix}_catalog with default schema
• Functions: Pure SQL UDFs for tokenization/detokenization
• Column Masks: Applied to sensitive columns only

Development

Adding New PII Columns

1. Update tokenization: Edit skyflow_databricks/databricks_ops/notebooks.py to include new columns in pii_columns
2. Add column masks: Edit skyflow_databricks/templates/sql/setup/apply_column_masks.sql
3. Redeploy: python setup.py recreate demo

CLI Features

• Databricks SDK Integration: Uses official SDK methods instead of raw API calls
• Better Error Handling: Detailed error messages and automatic retry logic
• Progress Indicators: Visual progress bars for long-running operations
• Rich Output: Colored, formatted output for better readability

Dashboard Integration

The included dashboard demonstrates real-time role-based data access with customer insights, purchase patterns, and consent tracking. The dashboard URL is provided after setup completion.

Cleanup

python setup.py destroy demo

Removes all UC resources: catalog, connections, secrets, functions, column masks, notebooks, and dashboards.

Support

• Skyflow Documentation: docs.skyflow.com
• Databricks Unity Catalog: docs.databricks.com/unity-catalog
• GitHub Issues: Please use the repository issue tracker

License

This project is provided as sample code for demonstration purposes. Not recommended for production deployment without further review, testing, and hardening.
